DN40 threaded 2-way globe valve from the Venta V241 series. Bronze body with stainless steel trim rated to PN16. Not rated for steam — suitable for water and glycol hydronic systems.
Certifications: PN16
Temperature Range: -4–302°F (-20–150°C)
Request a Quote →Specifications
| Size | DN40 (1-1/2 in) |
| Configuration | 2-Way |
| Connection | G External Thread |
| Cv | 25 kvs / 28.91 cv |
| Media | Water, Glycol 25–50% |
| Body Material | Bronze Rg5 |
| Trim Material | Stainless Steel AISI 303 |
| Stem Material | Stainless Steel AISI 303 |
| Pressure | 87 psi max delta P |
| Notes | PN16, bronze body, stainless trim, no steam |
Applications
- Hydronic Heating Systems
- Chilled Water Systems
- Building Automation Systems
- European Standard Installations
